Village Grove Apartments

Trumansburg, NY



Owner: Ithaca Neighborhood Housing Services  | Location: Trumansburg, NY | Completion Date: Ongoing
Programs Achieved: Passive House, NYSERDA Buildings of Excellence, NYSERDA New Construction – Housing Tier 4, DOE Net-Zero Energy Ready, EPA Indoor Air Plus Qualified, Enterprise Green Communities 2015, Energy Star Multifamily New Construction




Village Grove is the proposed development of a highly energy efficient 40 unit affordable multifamily rental building in Trumansburg, NY to be developed by Ithaca Neighborhood Housing Services (INHS). The project is targeting PHIUS+ 2018 Certification and has received a $932,280 Building of Excellence award for low carbon construction. The project features all electric systems including geothermal heat pumps for heating, cooling, and hot water systems, advanced insulation to meet PHIUS+ 2018, and off site solar production to achieve Net-Zero energy.  SCI will also serve as the PHIUS+ CPHC and Verifier to confirm all program requirements are met through construction and will conduct training on high-performance building practices.

Location Trumansburg, NY
Climate Zone 6
Average HERS Index 37 pre PV, -1 post PV
Square Footage 42,362 sf
Heating Degree Days 7,173



Technical Details

Walls Pre-fabricated, art Dash 12 continuous rigid insulation and 2 x 6 wood studs with R- 21 cavity insulation
Windows Triple pane windows and doors
Air Barrier The panels produced by Purcell will be constructed offsite in a controlled environment ensuring that the components are sealed to meet this requirement. Early and frequent pressure testing will help identify potential leakage paths so they can be addressed in real time.
Roof R-80
Slab R-15 slab edge
Heating/ Cooling Ground Source Heat Pump
Ventilation Two Central Energy Recovery Ventilation System, 72% recovery efficiency
Hot Water Ground source heat pump DAIKIN water-to-water heat pumps, EPA water sense fixtures, 2.5 EF
Solar Electric ~200,000 kWh/yr, located remotely at Renovus community solar farm. Project aims to achieve PHIUS+ Source Zero badge
